51Series
Machining Diameter from 1250mm to 2500mm
Our Products
Based on High-end Equipment, Weak-point Equipment, Intelligent Equipment Research, Development and Manufacturing
CNC Vertical Lathe Series
52 Series
Machining Diameter from 3500mm to 12500mm
Table Diameter from 1000mm to 12500mm
Loading capacity from 5 Ton to 800 Ton
53 Series
Machining Diameter from 12500mm to 28000mm
58 Series Machining Diameter Range from 4000mm to 10000mm,Loading Capacity Range from 30 Ton to 160 Ton
Full Hydrostatic Guild Way Structure Capable of replacing grinding by turning for quenching surface (Hardness HRC62) Parts Surface Roughness: Ra0.6 after hard turning Product Current Market Share: Over 80%
59 Series All-in-one turning and milling center, Machining Diameter Range from 1250mm to 3150mm, Loading Capacity Range from 5 Ton to 25 Ton
Five-axis Turing d Milling Flexible Machining
High-speed Turning and Milling Multi-functional Carriage
Heavy-duty High Rigidity Turning and Milling Multi-functional Work Table
Constant-flow Hydrostatic Guild Way
High Precision Heavy-duty Exchange Work Table
Multi-position Turning and Milling Magazine
On-Machine Measurement, On-Machine Monitoring
CNC Large Diameter High Precision Turning and Milling Center
Turning and Grinding Series Machining Diameter Range from 4000mm to 10000mm.
Particularly Applicable for High Precision Machining for Ring type and Disc Type Parts such as Bearing Ball Track, Gear Ring and etc
Turning and Milling Multi-functional Machining
High-precision closed hydrostatic bearing; Hydrostatic guide way work table
High-power High-precision grinding head
Grinding head run out:0.002mm; Work table run out:0.006mm
Positioning accuracy 0.01mm/1000mm。
Surface finish after grinding:Ra0.4
CNC Horizontal Lathe Series
WZ Series Machining Range:900mm to 2000mm Load Capacity Range:18 Ton to 32 Ton Sliding guide and high-precision spindle roller bearing Max Rotating Speed: 300 rpm
WL Series
Machining Range:1600mm to 5000mm Load Capacity Range:23 Ton to 320 Ton Hydrostatic guide way and high-precision spindle roller bearing Spindle run out:0.005mm
DL Series
Machining Range:2000mm to 6500mm
Load Capacity Range:125 Ton to 500 Ton
Hydrostatic guide way and Hydrostatic spindle
CNC Horizontal Lathe
Turing and milling carriage equipped with indexing milling head Suits for machining aero-space composite material cylindrical parts Suits for end-face, radial direction drilling and milling of engine parts
CNC High Precision Horizontal Lathe
Turbine rotor machining
High precision hydrostatic Center shaft rest
High precision headstock
ZTK Series CNC Deep Hole drilling and Boring Machine
Suits for nuclear power application, shipbuilding, Hydraulics industries
Max. Boring Diameter:2000mm
Max. Drilling Diameter:160mm
Max. Boring Depth:2500mm
CNC Milling and Boring Machine Series
TK69C Series Floor Type Boring and Milling Machine
Constant flow closed hydrostatic pressure structure
High-speed, High-precision, High-Torque Headstock
Y-axis machining height range: 3000mm-12000mm
HBA62/69 Series CNC Floor Type Milling and Boring Center
Boring Spindle Diameter：130mm~160mm
Machining Height Range：2m~4m
Spindle Rotating Speed：3000rpm
Thermally Symmetrical Structure
Centralized High-speed Headstock
Guide way adopts high precision rail after quenching or heavy duty linear roller rail
Headstock vertical movements adopt dual motors and pair ball screws synchronizing focus drive technology
HBA65/68 Series CNC Horizontal Milling and Boring Center
Boring Spindle Diameter Range: 130mm to 160mm Machining Height Range: 2000mm to 4000mm Spindle Rotating Speed: 3000rpm Two table exchange system to realize parts flexible manufacturing A wide range of comparable attachments
TDV Series Rotary Table
Constant flow hydrostatic guide way Load Capacity Range:10 Ton to 600 Ton Max. Table Dimension:6000mmX12000mm Table positioning accuracy: Standard series 10″,High precision series 6″
TDVP Series Tilting Rotary Table
Table bed adopt hydrostatic guide ways; Rotating and centering adopts generously dimensioned high precision cross cylinder roller bearing Load Capacity Range: 60 Ton to 160 Ton Table tilting: Twin hydraulic oil tank with automatic lifting Tilting angle: 0°-10°
High Efficiency Machining Center for Large sized composite material cylindrical parts
Floor Type Milling and Boring Machine separates main machine from horizontal indexing rotary faceplates combination
Centralized headstock
Headstock adopts dual motors and pair ball screws synchronizing focus drive technology
Turning and Milling Head with Max. Rotating Speed:4500rpm
Max. Machining Diameter:φ3500mm
Max. Machining Length: 9000mm
Multi-functional machining capabilities including turning, milling, boring, drilling and grooving, suits for machining rocket body type parts in aerospace industry.
CNC Portal Milling and Boring Machine Series
XK21/24 Series Main Specs：
Table Width Range: 2000mm to 5000mm
Table Length Range: 4000mm to 12000mm
Fully Hydrostatic guide way
Fully Enclosed Ram
Fully Automatic Indexing Boring and Milling head with Integrated C-axis/5-aixs Boring and Milling Head
XK26/27 Series Main Specs
Table Length Range: 8000mm to 64000mm Fully Hydrostatic guide way Fully Enclosed Ram Fully Automatic Indexing Boring and Milling head with Integrated C-axis/5-aixs Boring and Milling Head
XKC56 Series Portal Milling Machine-Gantry moveable Design
Fully Hydrostatic Guide ways High-performance Multi-functional Ram Integrated C-axis Auto Indexing High-precision Rotary Table with High Positioning Accuracy and Quick Inertia Response
XKC57 Series Portal Milling Machine-Gantry moveable Design
Rotary Table Diameter Range:3150mm to 11000mm Gantry Width Range:4000mm to 12500mm Ram Vertical Travel Range:2000mm to 4500mm
XKC56/57 Series
Wind Energy Industry Application
CNC Gear Hobbing Machine Series
YK31 Series CNC Gear Hobbing Machine 2000mm to 12500mm
Rotary table adopts closed type hydrostatic spindle centering and closed type hydrostatically guided load relief technologies to retain high precision without compromising high rigidity.
Rotary table adopts high precision double worm gear drive technology.
Gear hobbing machine Max accuracy:6; Tooth surface finish:Ra1.6
Optional high performance gear milling tool post for heavy duty application.
Optionally equips machine with fully enclosed protection.
Process methods are available in Dry-cut, air cooling and water cooling.
Railway Machine Series
Equipped with advanced CNC system to complete all following process:
Lifting and centering of wheelset
Measuring of wheelset tread diameter and wear surface
Machining parameter recommendation based on measurement data processing
Optimized profile machining cycle
Final measurement data storage
Brake disc machining
Gauge：900~1676mm
Wheelset Diameter：580~1400mm
Wheel Width：80~155mm
Specialized Machine Tool Series
XK97/99 Series Steel Rail Milling Machine
Structure Design for High Performance High Torque Machining
Constant-flow Type Hydrostatic Guide ways
Fully Automatic Hydraulic Clamp, Electromagnetic Suction Cups
Twin Head Synchronized Milling
Gantry Width：1750~4000mm
Spindle Qty：1~2
Spindle Rated Torque：3800~4500Nm
ZK54 Series Portal Drilling and Milling Machine Center with Multiple Spindles
High Speed High Torque Mechanical Spindle or Electronic Spindle with Higher Speed
High Performance Machining: Drilling, Milling, Rigid Tapping
Gantry Width：4300~7300mm
Spindle Qty：2~8
ZK55 Series Portal Drilling and Milling Machine Center with Multiple Spindles
XK95/96 Aluminum Ingot Milling Machine
High efficiency milling for aluminum ingot surface horizontally and vertically
Automated Production Line Series
Mega Parts Machining Line—Aircraft Magazine Turning and Milling Line
Aircraft Magazine Turning and Milling Line
5-Axis Turning and Milling Composite Flexible Line
High Precision Heavy Duty Exchange Work Table+AGV+RGV
Automatic Centering Chuck+Robotics
Mega Parts Machining Line—Arm Type Frame Rotary Table Machining Line
The auto production line equips with incoming material buffer area loading, intelligent distribution system(Distribution between operations, Auto docking: finished products to paint line loading area), Frame turntable intelligent machining line(Whole set of machine tools, flexible auto clamping, line management system), Intelligent inspection for dimensions and tolerance, unloading, burr and flash removal functions
Mega Parts Machining Line—Excavator Center Frame Machining Line
Technical core: CNC horizontal boring and milling machining centers; Processing equipments
key support: Work piece storage and distribution system
Information support: Line master control
Other Support: Centralized chip conveying system
The line is designed for excavator center frame structure parts machining, de-burring and inspection
Mega Parts Machining Line—Excavator Base Frame Machining Line
The line is designed for concrete pump truck base frame machining, de-burring and inspection. The auto production line equips with incoming material buffer area loading, intelligent distribution system(Distribution between operations, Auto docking: finished products to paint line loading area), base frame intelligent machining line(Whole set of machine tools, flexible auto clamping, line management system), Intelligent inspection for dimensions and tolerance, unloading functions
Mega Parts Machining Line—Rutting Fork Parts
Multiple equipments formed a straight line layout as designed, completing all operations by carrying out each machining process independently. The line is consisted of control system, flexible machining equipments, pallet exchange system, transfer roller conveyor, loading/unloading system, auxiliary equipments.
Small/Medium Parts Machining Line—Cylinder Machining Line
